4.3 Controls

All controls, inputs, and outputs of the Direct-Media are located on
the loudspeaker enclosure rear panel. Refer page 15.
A sturdy carrying handle is integrated in the Direct-Media.
(1) Main input
Main input jack for operating the Direct-Media on 230 VAC
power using the supplied cable.
(2) Power fuse
The power fuse is located below the power input socket. Prior
to replacing the power fuse unplug the Direct-Media from
power. Make sure to use replacement fuse of the same type as
the original fuse only:
1,25AT (5x20mm) for 230 VAC
(3) POWER switch (on/off)
Switches power to the Direct-Media audio section and amplifier
on and off. The STATUS LED in the POWER switch (3) will
illuminate red when power is on.
(4) Signal LED
Turn on the power switch (3) the power status indicator (4)
will light up.
(5) Peak LED
The overload indicator flashes when the loudspeaker´s on-board
amplifier are driven to their maximum signal output. Occasional
flashes are normal for very loud operation. However, if the
overload indicator stays lit, please reduce the power, because
the sound may be distored.
(6) LINE INPUT L/R
These two RCA jacks allow you to connect a CD player, cassette
recorder, or other line level source to your Direct-Media using
a stereo RCA cable (not supplied). The stereo input signal is
internally summed to mono.
Input sensitivity is 100 mV into 10 kΩ for nominal level.
(7) LINE INPUT
This jack 6,3mm allows you to connect a CD player, cassette
recorder, or other line level like keyborads and mixer sources to
your Direct-Media using a mono cable (not supplied).
Input sensitivity is 100 mV into 10 kΩ for nominal level.
(8) VOLUME
This rotary potentiometer sets the loudness volume of the
audio source connected to the LINE INPUT jacks (6) and (7).
Option wireless microphone in Direct-Media: This rotary
potentiometer sets the loudness volume of the wireless
microphone.
(9) mix/rec Output
This jack allows you to connect either a recorder or another
Direct-Media to your unit using a standard cable (not supplied).
This jack carrys the output signal of the built-in mixer with all
the volume and EQ settings you made. The output voltage at
nominal level is 1 V into 200 Ω source impedance.
(16) Mic input
This balanced female XLR connector allows you to connect a
wired microphone (optional) via a standard microphone cable
with a male XLR connector (optional). Since the microphone
INPUT provides 12 V phantom power you can connect both
dynamic and electret or condenser microphones.
Input sensitivy for nominal level is 2 mV into 1 kΩ.
Pin 1 is ground, pin 2 „hot" (inphase), pin 3 „hot" (outphase).
(12) VOLUME
This rotary potentiometer sets the loudness volume of the
microphone to the INPUT connector (16).
(13) Ground/Lift switch
This switch break the link between the amplifier´s circuit
ground and the amplifier chassis.
EQ tone control
The effective two-band equalizer is located in the signal path
immediately ahead of the power amplifier and therefore acts on
both the microphone/line input ch1 and the line input ch2.
(14) BASS
Rotary control for cutting or boosting the low frequencies.
(15) TREBLE
Rotary control for cutting or boosting the high frequencies.
wireless receiver (optional)
For details on the optional wireless built-in receiver to select
the carrier frequency please refer to the enclosed instruction
manual for the receiver.
Direct-Media | 11
