Pedal Plate Height Adjustment Instructions
Use a 2.5mm hexagonal spanner to turn the screws on the face of the pedal plate
counterclockwise and use a 7mm open-end spanned to remove the back nut from the plate
screws, move the plate up and down to adjust the plate height according to your needs,
then tighten the nuts and screws until they fit the plate and fix it. Same procedure applies to
all pedals.
Parameters
Pedal material
Pedal plate material
Colour
Sensing method
Pedal spacing
Pedal plate height
Pedal travel software adjustment
Pedal travel reversal function
Pedal output curve
Anti-slip pedal pad
High strength steel
High strength steel
Black
Hall sensor
Adjustable
Adjustable
Supported
Supported
Supported
Included
