C
Installation with a COMBI
2
– F ollow the steps below to install the Scale Control R with a Quooker COMBI B tank.
– E xtra materials required: Spanners size 17, 19 and 22 (2 ×).
1
3
A
4
5
2
On/off
B
6
B
A
10
1. Preparing the Tank
Switch off the tank, but leave the plug in
the socket with the power switched on.
2. Draining the Boiling water
Activate the boiling water tap (push—push—
turn) and run the cold water tap at the
same time. Let the water run until it is cold.
3. Disconnecting the Tank's Inlet Hose
Close the main stopcock or cold water
isolation valve (A). Disconnect the
tank's cold water inlet hose from the
mixer valve (B).
4. Connecting the Inlet Hose
Connect the Scale Control inlet hose
(long) to the mixer valve.
5. Connecting the Outlet Hose
Connect the Scale Control R outlet hose
(short) to the tank inlet hose with the
coupler and the blue fibre washer.
6. Flushing the Cartridge
Open the main stopcock or cold water iso-
lation valve. Flush the system by activating
the boiling water tap (push—push—turn)
and run for 20 seconds. Check for leakag-
es. Activate the boiling function again and
let the water run for about 5 minutes, until
the water runs clear. Switch on the tank.
Once the water has heated up again, the
Quooker system is ready for use.
