Material
Foam to foam
Read and observe the instructions supplied with all adhesives! The building
instructions inform you when to use particular glues. If you wish to use white
spirit or other solvent as a cleaning agent, note that special safety measures
are required. Read the instructions supplied with these materials.
Note
Important: it is essential to keep the model's weight to a minimum, so please be
sparing at all times when applying adhesives.
Read the instructions supplied with the various glues before using a particular type
on the model. You will find other adhesives in the main Graupner FS catalogue.
Radio control system for the FUN-FLY
27 MHz radio control system, included in the set
For the transmitter you will need six dry cells, Order No. 3426, or rechargeable cells
of the same size; see the main Graupner catalogue for details.
RC functions
Turn control: differential motor speed
Height: motor speed
Specification
Wingspan approx.
Overall length approx.
Wing area approx.
Weight approx.
Pack contents
Operating the model for the first time
Screw aerial in the transmitter. Remove the battery compartment cover on the
underside of the transmitter. Place the battery cells in the compartment, orientated as
shown in the illustration, then close the cover again.
Charging the flight battery
Switch the transmitter on by moving the slide switch to the ON position; the red LED
will light up. Open the flap at the top of the transmitter and locate the lead terminating
in a plug. Insert the plug in the socket on the underside of the fuselage.
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Änderungen vorbehalten! Keine Haftung für Druckfehler!
Typical joint
Wing
250 mm
230 mm
1.6 dm²
23 g
19
Adhesive, Order No.
UHU por 959 or
Cyano-acrylate 5821 with
Activator 953.150
06/2008
