Remove the paint needle before removing the paint nozzle, or hold the needle retracted,
4.
otherwise the seat may be damaged.
Insert the paint needle and screw on the paint needle seal by hand. Tighten carefully with
5.
a spanner. Adjust the seal while you press in the trigger and check how the paint needle
moves. Do not over-tighten, as the paint needle moves slower, which will result in leakage
from the nozzle tip.
If this is the case, loosen anti-clockwise until the needle moves freely without paint
6.
leakage.
Turn the pattern knob anti-clockwise to the fully open position and screw in the pattern
7.
guide in the body.
IMPORTANT: Only use spare parts and accessories recommended by the manufacturer.
Never immerse the spray gun in solvent or other fluid.
•
Be careful never to damage the holes in air cap, paint nozzle or paint nozzle.
•
Spray patterns Problem
•
•
Uneven
•
•
Half moon format
•
Thicker at one end
•
•
•
Thinner in the
middle
•
ENGLISH
TROUBLESHOOTING
Air leaks in between the paint
nozzle and the connection.
Air leaks in between the air
setting ring and body or the
connection.
Air leaks in by the needle lock
nut.
Air leaks in between the paint
hose and the container.
Clogged hole in the air cap.
Blockage between the paint
nozzle and air cap.
Blockage at the paint nozzle's
outlet.
Too low viscosity.
Excessive paint flow.
Action
Dismantle and clean the parts
•
and refit. Replace the parts if
they are damaged.
Dismantle and clean the parts
•
and refit. Replace the parts if
they are damaged.
Tighten the needle lock nut.
•
Dismantle and clean the parts
•
and refit.
Clean the nozzle with a nylon
•
brush (not a metal brush).
Clean the holes.
•
Replace the air cap if the holes
•
are damaged.
Remove the paint nozzle and
•
clean the connection.
Add undiluted paint too
•
increase the viscosity.
