Parts
Transmitter Control Unit(TCU)
1. LCD Screen
2. Options Button
3. Mode Button
4. Zoom Button
5. Power Button
6. LED
7. + / - Buttons
8. Selection Buttons
9. Clear Button
2
10. High Speed Sync Button
11. Modeling Light Button
12. Test Button
13. Battery Compartment
14. Hot Shoe Lock Release
Button
15. Hot Shoe
16. USB port
1
3
2
8
6
13
12 9 10 11
15
4
5
7
16
