Lights up purple
Lights up red:
3s
Centronic PLUS transmitter selected.
No receiver located.
Briefly press the programming button on the transmitter
to change to the setting mode.
▻ The receiver with the best connection quality to
the transmitter confirms.
▻ The LED ring lights up white in the lower area
and shows the current assignment status of the
selected sensor in the upper area.
If a sensor/receiver has not yet been added to the
installation (LED ring lights up yellow), it will not be
possible to select it in this way. The sensor/receiver
must be added to the installation beforehand.
Assignment status in the upper area of the LED ring
Lights up blue:
Lights up green: The receiver is assigned to the se-
Lights up red:
If you do not receive confirmation from the required re-
ceiver, you can press the / button to toggle between
the available receivers until the required receiver con-
firms.
Press the STOP button on the transmitter to change the
assignment status of the selected receiver. If the re-
ceiver is still not assigned to the selected sensor, it will
or
now be added.
▻ The receiver signals once to confirm the sensor
assignment, or signals twice to cancel the
sensor assignment.
▻ The transmitter lights up accordingly to confirm
the new assignment status.
Then press the programming button on the transmitter
for 3 seconds to change to normal mode.
► The LED ring goes out.
The receiver is not assigned to the
selected sensor.
lected sensor.
No receiver located.
