Instructions for Reverse Trigger Wiring
To use the reversing function, install the rear camera in position B,
then connect the red cable of rear camera extension cable to the
anode of the car reversing lamp.
Rear Camera
Rear
Red
Line
Reversing Lamp
Reversing Lamp Positive Lead
Wire Layout in the Vehicle
1. Plug the car charger into the mirror dash cam and connect it to
the cigarette lighter.
2. Attach the GPS module to the GPS port, remove its sticker, and
place it on your car dashboard.
3. Start your car's ignition and watch as the dashcam powers on
automatically.
EN-09
