3.2 Oscilloscope Parameters
Parameters
Real-time Sampling rate
Analog Bandwidth
Input Impedance
Coupling Mode
Test Voltage Range
Vertical Sensitivity
Vertical Displacement
Level Time Base
Trigger Mode
Trigger Type
Trigger Level
Waveform Freeze
Auto Measurement
Specification
DST-201
5MSa/s
1MHz
1MΩ
AC/DC
1:1 Probe:80Vpp(±40V)
10:1 Probe:800Vpp(±400V)
10mV/div~10V/div
Adjustable with indicators
500ns~20s
Auto/Normal/Single
Rising Edge & Falling Edge
Adjustable with indicators
Support(HOLD function)
Maximum, Minimum, Average, RMS,
VPP, Frequency, Period, Duty Cycle
Remarks
DST-210
48MSa/s
10MHz
Oscilloscope
sets X1 gear
Oscilloscope
sets X10 gear
50ns~20s
EN
X1 gear
