Hardware parts (variations possible)
Rubber strip Φ3*16
10m 1x

ASSEMBLE INSTRUCTIONS

Assemble tips
Please remove transport packaging and inspect that your infrared cabin has been delivered complete
and intact before beginning assemble.
A least 2 persons are required for assemble of the cabin
Please check the countersink and hole diameter of the drill holes to avoid damaging the wood.
The minimum room height required for installation is 2120 mm
Tools
Screwdriver (kit)
Spiral drill (kit)
Allen Wrench (kit)
Spirit level
Φ4*45 Φ6*60 30*20*2
57x
2x
1x
Tape measure
Hammer
Cutter
Pencil
EN
Electric drill
Stepladder
