Setting Upper and Lower Limits:
Setting Lower Limit:
Adjust table to desired lower limit height. Press and hold the "M" key on the controller.
The display shows "S-" release the "M" key, then press and hold the "Down Arrow" Key.
The display will flash once, release the "Down Arrow" Key; then press and hold the "M" Key for 2
seconds.
The display will read "00.0" indicating the current height has been set as the lower limit.
Setting Upper Limit:
1) Adjust table to desired upper limit height. Press and hold the "M" key on the controller.
2) The display shows "S-" release the "M" key, then press and hold the "Up Arrow" Key.
The display will flash once, release the "Up Arrow" Key; then press and hold the "M" Key for 2
seconds.
The display will read "99.9" indicating the current height has been set as the upper limit.
Locking Mode:
Long press the "M" key for 8 seconds. The display will briefly show "S-" followed by "LOC" which
indicates the controller has been locked and the keys will not function.
To exit lock state, long press the "M" key for 8 seconds. The controller will resume full functionality.
Technical Data
Model #
Input
Rated Power
Duty Cycle
Rated Load
Noise Level
CAUTION: To avoid damage to the table do not exceed listed duty cycle.
16
FQ13072D-X
FQ13060D-X
FQ12460D-X
FQ12448D-X(where X is W, B, G, or other colors, without other construction differences)
220-240V AC
600W
10%, Max 2min On / 18min OFF
100kg (220 lb)
LpA ≤ 53 dB(A)
