Uninstalling the panel
Disconnect the panel from the mains using a two-pole switch before uninstalling it. Lift the panel upwards
vertically and sideways in such a way that it is released from the screws. Furthermore, the supply cable
must be disconnected from the box on the wall.
Technical specifications
Dimensions
Weight Output Current Voltage Protection
Type (mm) Coverage
(kg) (W) (A) (V) AC class
(LxWxH)
Ecosun 750 IKP 1192x592x30 11 750 3,3
230 V I IP 54
The panel can be installed on bases of flammability class C or D.
Fig. 5 Mounting
W A B
W A B
(mm) (mm)
(mm) (mm)
750 935 280
750 935 360
