07
Lift the Seat Slider Lever and slide the Seat Rails all the way back to access the rear mounting slots on
the Seat Slider Rail.
A)
08
A) Align the Seat Slider rear mounting slots, with the T-Nuts in the rear 4040 Extrusion.
B) Bolt through and secure with M8 Bolts.
A)
A) Lift the Seat Slider Lever up and slide the Seat all the way back to access the front mounting holes.
09
Align the Seat Slider front mounting holes with the T-Nuts in the front 4040 Extrusions.
B) Bolt through and secure with the M8 Bolts.
B)
NOTE: Partially tighten bolts
with fingers, then secure using
Allen Key.
Repeat
on Other
Side
B)
NOTE: Partially tighten bolts
with fingers, then secure using
Allen Key.
Repeat
on Other
Side
10
PARTS:
• • NIL
PARTS:
• • 2 x M8 16mm Bolts
• • 2 x M8 Spring Washers
Note: Use Spring Washers with M8
Bolts when installing Seat to the
F-GT Elite Cockpit.
PARTS:
• • 2 x M8 16mm Bolts
• • 2 x M8 Spring Washers
Note: Use Spring Washers with M8
Bolts when installing Seat to the
F-GT Elite Cockpit.
