COMPLIANCE
SYSTEM CONNECTION
Supply types / number of wires
Management
frequency
SUPPLY
CONSUMPTION
Supply
Current circuit
CURRENT (TRMS)
Starting current (ist)
Minimum current (imin)
transition current (itr)
reference current (iref)
Permanent overload (imax)
Short-term over-current
VOLTAGE (TRMS)
Direct measurement
Permanent overload
POWERS
Active
reactive
Resolution
ENERGY
s Active
reactive
Total and partial metering
Bidirectional metering (eA+ and eA-)
Resolution
ACCURACY
Active energy
TARIFFS
tariff management
number of tariffs managed
tariff exchange input
METROLOGICAL LED
impulse weight
Colour
DISPLAY
type
Refresh time
Back-lighting illumination time
List of functions displayed
* functions available only via communication, the complete list of these functions is given in the down-
loadable M-BUS communication table.
european eMC Directive no. 2004/108/eC (15/12/2004)
Lv Directive no. 2006/95/eC Dated 12 December 2006
ieC 62053-21 / ieC 62052-11
Single phase 2 wires 230v / two phase 2 wires 400v
Three phase 3 wires 3x230 V / 3x400 V and Three phase 4 wires
3x230/400 V
Detection of cabling error
50 and 60 Hz (± 5 Hz)
Autosupplied
< 10 VA or 2 W
< 1.0 VA
10 mA
50 mA
250 mA
5 A
6 A
120 A for 0.5 s (en50470-3 and ieC 62053-21)
230 V AC Phase/Neutral 400 V AC Phase/Phase ± 15%
230 / 400 V AC + 15%
yes
no*
0.1 kW
yes
yes
Yes (0 to 9999999 kWh)
yes
1 kWh
Class 1 (ieC 62053-21)
yes*
4*
no*
10000 impulses / kWh
red
7 Digit LeD with blue back-lighting
1 s
30 s
Cf. table below
