Man & Machine C Mouse Wireless Bedienungsanleitung

Operating Manual • Bedienungsanleitung • Mode d'emploi • Manual de usuario
• Manual do usuário • Istruzioni d'uso • Gebruikshandleiding • Installation • Instrukcja obsługi
B
2
2
Part functions:
EN
1
USB-C Port: Used to charge the mouse. Cover during washing or
rinsing. USB-C Port Cover is located on bottom of mouse.
2
Charging cable: Used to charge the mouse.
USB-C Port Cover: Used to cover the USB-C port during washing
3
or cleaning.
4
POWER button
5 Mode button
Scroll wheel
6
LED indicator: RED: mouse battery is charging; Blinking GREEN:
7
mouse is attempting to pair to USB Dongle (8); Solid GREEN:
mouse is paired to USB Dongle (8) and connected to the
computer; Blinking BLUE: mouse is attempting to pair via
Bluetooth TM ; Solid BLUE: mouse is paired and connected to the
computer via Bluetooth
USB Dongle: Plugs to a computer USB port. Allows the mouse to
8
connect to the computer wirelessly. The USB dongle comes in the
box with each mouse.
9 USB-C Port Cover storage: Keep the USB-C Port Cover (3) in the
storage space (9) when it is not in use to cover the USB-C Port (1)
during washing and cleaning.
Sensor Light
10
Power ON/OFF:
Press and hold the POWER (4) button for 3 seconds to turn the mouse ON or OFF.
Switching Between Modes:
Man & Machine C Mouse Wireless supports both RF mode and Bluetooth
Use the MODE button to switch between these modes as needed.
Pairing Instructions:
If using RF mode, ensure the dongle is properly connected to the USB port. If
TM
using Bluetooth mode, select the appropriate Bluetooth
pairing. Follow the Quick Reference Table below for detailed pairing instructions.
Note: To pair the mouse in RF or Bluetooth mode, it must first be set to the
corresponding mode before beginning the pairing process.
C Mouse Wireless
8
2.4 GHz
6
1
(See figures A and B)
TM .
TM
version during
BT
7
3
3
Quick Reference Table:
Function
Power ON/OFF
Switch to Bluetooth
Mode
Switch to RF (dongle)
Mode
Pair to another
dongle (RF mode)
Pair with Bluetooth
(3.0 or 5.0)
Note: The mouse is already paired with the USB dongle that comes with it. If you
are using this mouse in combination with the Man & Machine Its Cool Flat
Wireless, you can use one USB Dongle to operate both devices. Once you have
installed the first device with its dongle, connect the other device to the same
dongle by following its connected pairing procedure.
Troubleshooting:
If you experience connectivity issues, try the following steps. Ensure the mouse is
fully charged. Restart the pairing process following the steps in the Quick
Reference Table. Verify that your device supports the selected Bluetooth
version.
Battery charging:
Remove the USB-C Port Cover (3) to expose the USB-C port (1). Place the USB
TM
mode.
Port Cover (3) in the USB Port Cover Storage Space (9). Connect USB connector to
a 5V/1A USB charging device. LED indicator (7) will turn RED when charging. The
LED indicator (7) will turn off when fully charged. Replace the USB-C Port Cover
(3) over the USB-C charging port (1). Note: The mouse will not work, or may act
erratically, if the battery is depleted or low. Charge timely following procedure
described above.
Approved cleaning methods
• You can wipe the product with a soft cloth that is non-abrasive such as a
microfiber cloth, a disinfecting wipe, a soft brush similar to a paint brush in
bristle stiffness or a sponge, but not a scourer of any sort.
• You can rinse the product with soap and water or an approved disinfectant.
Before first installation, fully charge the
battery using a 5V/1A USB charging
device and the included USB-C cable.
6
5
10
Action
Press & hold the POWER (4) button for 3
seconds
Short press MODE (5) button; BLUE LED (7) will
TM
blink slowly (trying to acquire a known BT
device).
Short press MODE (5) button; GREEN LED (7)
will flash slowly (trying to acquire a known RF
dongle).
Press Left, Right, & Center (wheel) buttons
simultaneously → GREEN LED (7) will blink fast
(20 sec) → Hold mouse near dongle → Unplug
& reinsert dongle to complete pairing
Press & hold MODE (5) button for 3 seconds →
TM
BLUE LED (7) will blink fast (120 sec) → Hold
mouse near BT device → Select version (3.0 or
5.0)
4
3
9
A
TM
