Controls
The sE6160 features two switches:
Attenuation Pad
The attenuation switch allows you to reduce the microphone's signal by 10 or 20
decibels. This can be helpful for loud sources, preventing overload on your audio
interface. When this switch is in its center position, it has no effect on the
microphone output.
Low-Cut Filter
The low-cut switch allows you to adjust the bass response of your source. When
engaged, the microphone's low-frequency response is rolled off at 80 or 160 Hz.
When this switch is in its center position, it has no effect on the microphone output.
Technical specifications
Capsule
Polar patterns
Frequency range
Sensitivity
Max. SPL (0.5% THD)
Equivalent noise level
Dynamic range
Signal-to-noise ratio
Low-cut filter
Attenuation pad
Powering
Electrical impedance
Recommended load impedance
Current consumption
Connectivity
Dimensions
Weight
Hand-crafted small-diaphragm true condenser capsule
Shotgun (super-cardioid/lobar)
20 – 20,000 Hz
25 mV/Pa (-32 dBV)
137 / 147 / 157 dB (0/10/20 dB attenuation pad)
SPL
13 dB(A)
124 / 134 / 144 dB (0/10/20 dB attenuation pad)
81 dB
80 / 160 Hz, 6 dB/oct, switchable
10 / 20 dB, switchable
48 Volts according to IEC 61938
110 Ohms
>1k Ohms
2.6 mA
3-pin male XLR connector
19.6 x 250 mm (ø x H)
0.77 x 9.84 in. (ø x H)
110 g (3.88 oz.)
