Carl Martin Greg Howe's LickBox Bedienungsanleitung Seite 5

Power Requirements
The Greg Howe's Lick Box comes with the innovative Carl Martin DC/DC circuitry that delivers internally +-12V
regulated.
Power consumption: max. 100 mA
Power supply: 9 V DC (regulated), 150 mA minimum, 2.1 mm female plug, center negative (-)
ATTENTION: Please use an external DC Power Supply only, failure to do so may damage the unit and void
the warranty. This pedal CAN NOT be powered by a 9V battery, only by an external Power Supply (not included)!
Specifications
• Input: 1M Ohm
• Output: 200 Ohm
• S/N Ratio: 54 dB
• Gain Max Crunch: +60 dB
• Gain Max: +89 dB
• Boost Max: +12 dB
• Dimensions: 186 (W) x 120 (D) x 55 (H) mm
7.31" (W) x 4.72" (D) x 2.16" (H)
• Weight: 820g / 1,81lbs
Warranty
Carl Martin Research warrants the manufacturing, material and proper operation for a period of one year from
date of purchase. Carl Martin will replace defective parts, make necessary repairs or replace the unit at the
discretion of our technicians. The warranty applies only to the original purchaser of this product, and excludes
any damage or faulty operation resulting from misuse, neglect or unauthorized service.
Environmental Compliance
WEEE Directive
This product complies with the EU Directive 2012/19/EU on Waste Electrical and Electronic Equipment
(WEEE). Dispose of this product responsibly at an appropriate recycling facility. Do not discard with household
waste.
CE Marking
This product meets all essential health, safety, and environmental protection requirements of the Euro-
pean Union.
5 Carl Martin Greg Howe's LickBox User Manual
