General Safety
WARNING: Read all safety warnings and all instructions.
WARNING: For the correct and safe use of the router whilst
equipped with a template guide, refer to the safety warnings
and instructions in the manual supplied with the router.
Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Product Familiarisation
1. Guide Plate (to suit Triton router model TRA001)
2. Guide Plate (to suit Triton router models MOF001 & JOF001)
3. Alignment Bush (and Porter Cable guide bush adaptor)
4. M4 Screws
5. Guide Bushes
6. Table Spacer
Intended Use
Accessory kit for the fitting of guide bushes to Triton plunge routers,
for template routing and use of custom jigs, including different
diameter guide bushes, guide plates and spacer for operation in
router tables.
Not for commercial use
The tool must ONLY be used for its intended purpose. Any use other
than those mentioned in this manual will be considered a case
of misuse. The operator, and not the manufacturer, shall be liable
for any damage or injury resulting from such cases of misuse. The
manufacturer shall not be liable for any modifications made to the
tool, nor for any damage resulting from such modifications.
Before Use
WARNING: Disconnect the router from the power supply
before attempting to attach or remove the template guides.
WARNING: Wear suitable safety gloves when handling
router bits
Note: To use the Guide Bushes (5, A – H) for template routing,
you must first fit the Guide Plate (1 or 2) to the base of your Triton
router.
Preparing the guide plate
1. Choose the correct Guide Plate (1 or 2) that fits your Triton
router model (see 'Product Familiarisation')
2. Loosely fit the two M4 Screws (4) into the holes in the depressed
side of the Guide Plate, leaving a 3mm gap under each screw
head
3. Sit the Alignment Bush (3), recessed side up, in the centre of the
Guide Plate with the two notches aligned with the screw heads
4. Rotate the Alignment Bush until the notches no longer align
with the screw heads, then tighten the screws using a suitable
screwdriver (not included) to secure the Alignment Bush to the
Guide Plate
Fitting the guide plate to the Triton JOF001 and
MOF001 plunge routers (Fig. I)
1. Turn the Triton router upside down and plunge it to the collet
lock position
2. Remove router bit, if installed
3. Using a suitable screwdriver (not included), unscrew the four
Phillips screws that secure the black plastic baseplate. Remove
the baseplate
4. Fit the Guide Plate (2) into the dedicated recess on the inside
surface of the plastic baseplate (i.e. in between the router base
and the baseplate, see Fig. I)
5. Position the Guide Plate (2) over the router collet on to the
router base
Note: Ensure the plastic baseplate is centred on the router base,
and that all four screw holes are correctly aligned.
6. Reinstall all four Phillips screws, and tighten securely
IMPORTANT: DO NOT overtighten, as this can distort the baseplate.
Fitting the guide plate to the Triton TRA001 plunge
router (Fig. II)
1. Turn the Triton router upside down and plunge it to the collet
lock position
2. Remove router bit, if installed
3. Using a suitable screwdriver (not included), unscrew the four
Phillips screws that secure the black plastic baseplate. Remove
the baseplate
4. Position the Guide Plate (1) over the router collet on to the
router base
Note: Ensure all holes in the Guide Plate line up with the
corresponding holes in the router base.
5. Sandwich the black plastic baseplate on top of the Guide Plate
6. Reinstall all four Phillips screws, and tighten securely
IMPORTANT: DO NOT overtighten, as this can distort the baseplate.
Fitting a guide bush to the guide plate
1. Fit a cutter in the router collet and adjust the plunge until the
cutter is hidden
2. Loosen the two M4 Screws (4), remove the Alignment Bush (3)
and in its place fit the Guide Bush (5, A – H) required. Fit the
guide bush with its collar side up, pointing away from the body
of the router
3. Rotate the cutter by hand to ensure there is complete clearance
between the cutter and the guide bush
Fitting Porter Cable guide bushes to the guide plate
(Fig. III)
1. Loosen the M4 Screws (4) and remove the Alignment Bush (3)
from the Guide Plate (1 or 2)
2. Fit the Porter Cable guide bush into the recessed side of the
Alignment Bush
3. Fit this assembly to the Guide Plate
Table-mounted use (Fig. III)
Note: The Table Spacer (6) is required when template routing on a
router table.
1. Remove the insert ring from your router table
2. Remove the M4 Screws (4) and Alignment Bush (3) from the
Guide Plate (1 or 2), and sit the Table Spacer (6), recessed side
up, into the centre of the Guide Plate
3. Align the screw holes, then fit the screws and the required
Guide Bush (5, A – H)
