Taurus Pro Lat Pulldown Montage- Und Bedienungsanleitung Seite 32

Exploded View and Parts List
Right Arm Frame ASSY
Exploded View and Parts List
Right Frame ASSY
Part No.
Grade No.
6.1 IFP13010600
6.2 GB2766205-2ZC3
6.3 KPSFID2800
6.4 CWRVL0052000
6.5 GB77M8*6DHS2
Part No.
Grade No.
7.1 IFP13010700
7.2 RS17000400
7.3 GB70M10*20DHS20NL
7.4 BB1500
7.5 GB5780M12*155DHS20
7.6 GB9512DHS2
7.7 NM12DHS2
Part No.
Grade No.
8.1 IFP13010800
8.2 RS17000400
32
8.3 GB70M10*20DHS20NL
8.4 BB1500
8.5 GB5780M12*155DHS20
8.6 GB9512DHS2
(6)
(8)
Description
Left Arm Frame
Deep Groove Ball Bearing Φ25*Φ52*15
Plastic Insert Cap □50.8*76.2
Small Limit Sleeve
Socket Set Screw M8*6
Description
Left Frame
Rubber Bumper
Socket Head Cap Screw M10*20
Limit Sleeve
Hex Head Bolt M12*155
Flat Washer Φ13.5*Φ27*2
Nylon Lock Nut M12
10
Description
Right Frame
Rubber Bumper
Socket Head Cap Screw M10*20
Limit Sleeve
Hex Head Bolt M12*155
Flat Washer Φ13.5*Φ27*2
Left Frame ASSY
Weight Horn ASSY
QTY
1
2
2
1
1
QTY
1
1
2
1
1
2
1
QTY
1
1
Pro Lat Pulldown
2
1
1
2
(7)
(10)
