2 Product description
2 Product description
The modular frame structures define the spaces by creating a
home for active, dynamic teams. Flex Active Frames
provides spatial boundaries, vertical and horizontal surfaces
for collaboration and storage space for team organisation.
Flex Active Frames consists of individual elements that are
combined to create the required user environment.
The modular system of the Flex Active Frames is based on a
400 mm grid in width (1W, 2W), depth (1D, 2D) and height
(1H, 2H, 3H, 4H, 5H).
2.1 Technical data
EN
6
Straight (base and
extension unit)
Dimensions
Grid width (W): 400/800 mm
(Single unit: 435/835 mm)
Grid depth (D): 400 mm
(Single unit: 435 mm)
Height (H): 515 mm (1H), 915 mm
(2H), 1315 mm (3H), 1715 mm (4H),
2115 mm (5H)
