Control Board

The Control Board offers several features: you can simply set the starting address, run the pre-programmed
program or make a reset.
The main menu is accessed by pressing Menu until the display is lit. Browse through the menu by pressing
Up or Down. Press the Enter button twice in order to select the desired menu. You can change the selection
by pressing Up or Down. Confirm every selection by pressing the Enter button. You can leave every mode
by pressing the Menu button. The functions provided are described in the following sections.
Sub
Main
menu
menu
DMX Address
Run Mode
Channel Mode
Program Mode
Set Setting
Program Speed
Sound Mode
Sound Sens
Dimmer Mode
DMX Signal
Load Default
Master Signal
Display Back
Display
001~ XXX DMX address setting
DMX DMX controlled mode
Slave mode –
Slave
usable for the modes: One and Sound
Master mode internal programs (arranged
One
in a row)
Master mode sound controlled programs
Sound
(arranged in a row)
Master mode over 4 puzzles (arranged in a
M:2*2
square)
Master mode over 16 puzzles (arranged in
M:4*4
a square)
Slave setting (SL-02_SL-16) for
arrangement of several puzzles in a square
SL-01-SL-16
(please also note the instructions on the
following pages)
3CH
5CH
8CH Setting DMX channel mode
9CH
100CH
01 ...
Internal programs /
20
Auto program
AUTO
00 ...
Speed internal programs (increasing)
31
01 ...
Sound controlled programs
04
00 ...
Setting microphone sensitivity
99 (increasing)
OFF
DIM1
No function / not occupied
DIM2
DIM3
CLEAR
Run if there is no DMX-signal
KEEP
Yes
Restore factory settings
No
Enables or disenables the master signal
ON
Set the master signal to ON for the master
devices in the run modes: M4*4, M2*2, One
and Sound.
OFF
For all other uses set the master signal to
OFF.
ON
Display reverse 180 degree
OFF
33/42
