Mill SG2000MEC Bedienungsanleitung Seite 7

Specification
Model Thermostat
SG2000MEC Mechanical
SG2000LED Electronic
SG2000GLASS Electronic
SG2000LED BLACK Electronic
CO2200MECMAX Mechanical
CO2200LEDMAX Electronic
Before first use
After unpacking the heater, check to make sure the product was not damaged during
transport. Contact the retailer or importer if you discover any visible damages to the
product.
Keep the outer packaging to transport the heater in the future. If you want to dispose the
packaging, make sure it is done properly. Keep plastic bags away from children.
First use
After turning on the heater for the first time or after an extended period without use, the
heater can produce a burnt odor for a short time. This is normal.
Please read all the instructions carefully before use. Save the instruction manual for future
use.
Description of heater
Please see table above for which models that have mechanical/electronic thermostats.
A B
See figure 1 on separate illustration sheet
and Mechanical thermostat
1. Heat emission
2. Thermostat
3. Output selector
4. Legs (plastic)
Parts
A
See figure 2 on separate illustration sheet
Mechanical Thermost
• 4 screws (pre-mounted)
• 2 foot brackets
• 2 rails for the feet
Color Amperage
White 220-240V~, 50-60Hz
White 220-240V~, 50-60Hz
White 220-240V~, 50-60Hz
Black 220-240V~, 50-60Hz
White 220-240V~, 50-60Hz
White 220-240V~, 50-60Hz
C D E
, und
1. Heat emission
2. LED display
3. Thermostat + output selector
4. Fan (does not apply to CO2200LEDMAX)
5. ON/OFF
6. Legs (aluminium)
B
Electronic Thermostat
• 8 screws (pre-mounted)
• 2 foot brackets
• 2 rails for the feet
Power (W) Fan
1800-2000 No
1800-2000 Yes
1800-2000 Yes
1800-2000 Yes
1900-2200 No
1900-2200 No
Elektronisch Thermostat
5
