ATTENTION! Your Compact ComposTumbler may be too large to fit through some doorways when
assembled. You should build it in a space with easy access to the area where it will be used.
Assembly is divided into two major sub-assemblies: Drum and Support Frame.
DRUM ASSEMBLY
STEP 1 – JOINING THE DRUM PANELS
WHAT YOU'LL NEED
Tools:
Regular screwdriver
3/8" wrench
Hardware:
1a - (5) 10-32 x 3/8 Machine screw (silver)
1b - (5) 10-32 Serrated flange locknut
Parts:
Item 1 - (2) Drum panel segments
1.1
Place the drum panels (item 1) on a flat surface with the mixing fins facing up.
4
Watch the instruction
videos found on
Mantis.com to get
started in no time!
Mixing Fins
