Adjustments
5.2 Optional accessories: height adjustable support HVA
When using the device in "batch operation", for gripping of single stone slabs batched one upon the
other, we advise to use the accessories "height adjustable support"!
This way the inside height stays the same for gripping goods with the same dimensions, see Fig.
When gripping in batch operation, only the uppermost stone slab may be gripped at any time.
Caution while adjusting of the gripping range. There is danger of injuring the
hands! Use safety gloves. →
•
The height adjustable support (A) is attached to the
mounting plate (B), see Fig.
•
Adjust the height adjustable support (A) with the
adjusting screws (C), so both halves have the same
height and that the rubber gripper bars are positioned in
the middle to lower area of stone thickness, see Fig. →
