Fig. 1 :
mFlipLock access/
e-access panic/security/
multipoint locking
Tab. 1 :
Product variants
Product information
Product variant identification markings
Identifica- Meaning
tion
PE / access Panic function E ("mFlipLock access with panic function E", page 51)
PB / e-access Panic function B (switchover function)
("mFlipLock e- access with panic function B", page 51)
SV Self-locking
ZF Suitable for double-leaf doors
DIN left
Depending on closing direction of the door
DIN right
Product variant
example for a
single-leaf door
Product variant
example for a
double-leaf door
Evaluation control
system
