BOX CONTENTS
CHECK THAT THE CONTENTS OF YOUR BOX ARE CORRECT
ACCORDING TO THE MODEL
1 3
1 6
2 7
3 8
4 9
5 0
2
X Z
Y C
4
5
7
8
6
9
10
12
10
TOOLS REQUIRED
• Power drill
• Drill bits 4mm ( 3 / ), 10mm ( 3 / ) and 13mm ( 4 / )
16 8 8
• Phillips screwdriver size 2
• Small flat screwdriver
• Pliers
• Pencil
5
Surface Latch
1 Front plate (CL100 example shown)
2 Surface Latch unit (with packing pieces)
3 Neoprene seal
4 Spring loaded spindle
5 Spindle adaptor
6 Allen Key x1
7 Surface Keep Plate with x2 wood screws
8 Tweezers (for changing the code – mechanical models only)
9 Fixed length posts x2
10 Fixed length bolts x4
14
11 Code Change Tool (CL160 model only)
12 Code card (mechanical models only)
13 2 Keys (Key Override models only)
13
14 Tumblers x2 (CL100/CL200/CL400 models only)
15 AAA Batteries x2 (CL2000 series only)
Installation Instructions printed literature
11
15
The Surface Latch model is designed for in-swing* gates with
a thickness between 35mm (1 3 / ) to 60mm (2
8
*The latch bolt can be reversed to suit an outswing door.
If installing to an outswing door an additional strike plate should
be fitted to the post, frame, or closed leaf to protect the timber
from damage when the gate or door closes.
A Surface Keep plate is included as standard. Optional Plates
are available on request, if required.
6
3 / ) thick.
8
Installation Instructions
Surface Latch
