Grohe START 1012430000 Installationsanleitung Seite 13

GB
Intended use:
This product is intended for domestic kitchen
use for preparing food and washing dishes.
Safety notes
Prevent danger resulting from damaged voltage
supply cables.
If damaged, the voltage supply cable must be replaced
by the manufacturer or his customer service
department or an equally qualified person.
• Installation is only possible in frost-free rooms.
• The plug-in voltage supply is only suitable for indoor use.
• The plug-in connectors must not be directly or indirectly
sprayed with water when cleaning.
• The voltage supply must be separately switchable.
• Use only genuine replacement parts and accessories.
The use of other parts will result in voiding of the warranty
and the CE identification, and could lead to injuries.
This device may be used by children over 8 years of
age, as well as persons with physical, sensory, or
mental disabilities or inadequate experience and
knowledge, if they are under supervision or were
instructed in the safe use of the device and understand the
resulting risks. Children must not play with the device.
Cleaning and user maintenance must not be carried out by
children without supervision.
Battery information
Use the batteries supplied as standard for the initial start-up.
Ensure polarity is correct when inserting batteries! Only use
batteries of the same type. Always replace all batteries at the
same time, do not mix new and used batteries together. Do not
recharge used batteries, and do not attempt to reactivate them
using heat or other means. Rechargeable batteries may not be
used. Discharged batteries must be removed from the device
immediately, increased risk of leakage!
Technical data
• Battery type:
• Power consumption:
• Automatic safety shut-off:
(6 - 420 s adjustable)
• Run-on time (0 - 19 s adjustable):
• Reception range according to Novoflex Zebra XL Grey Card,
grey side, 8x10", landscape, 0 - 8 cm adjustable
Fault / Cause / Remedy
Fault
Water not flowing
Undesired water
flow
Flow rate too low
6 V lithium battery type CR-P2
Cause
• Filter upstream of solenoid valve blocked
• Solenoid valve defective
• Plug-in connector without contact
• No voltage
- Battery discharged
• Sensor system detection zone set too high
for local conditions
• Solenoid valve defective
• Mousseur dirty
• Filter upstream of solenoid valve dirty
• Type of fitting protection:
Electrical test data
• Software class
If static pressures exceed 0.5 MPa, a pressure-reducing valve
must be installed.
Avoid major pressure differences between hot and cold water
supply!
Operation and settings
Activating setting mode
Disconnect the power supply to the electronics and
reconnect after 10 s.
The indicator lamp in the sensor system illuminates in setting
mode when the detection zone of the fitting is reached by an
approaching user.
Setting mode is automatically terminated after 3 minutes.
Maintenance
Batteries which are almost discharged are displayed
by a flashing indicator lamp in the sensor system
Care
For directions on the care of this fitting, please refer to the
accompanying Care Instructions.
Disposal note
Items with this label should not go in domestic waste.
These items should de disposed of separately from
domestic waste and recycled in accordance with local
environmental regulations on waste disposal. This measure
minimises the potential negative impact on human health and
the environment.
Special accessories
The factory settings can be
changed and special functions can be activated,
deactivated and set using the infrared remote control
2.4 W (Prod. no. 36 407). The current Technical Product
60 s Information for the remote control can be downloaded
from www.grohe.com/tpi/remote-control.
1 s
Automatic flushing cannot be activated for this product.
Remedy
- Clean or replace filter
- Replace solenoid valve
- Check plug-in connector
- Replace battery
- Reduce range using remote control (special
accessory, prod. no.: 36 407) / app
- Replace solenoid valve
- Clean or replace mousseur
- Clean filter
12
IP 59
A
