Units Of Measure; Scan Function - Noblex Nf 10X42 R Advanced Gebrauchsanleitung

has been targeted, the symbol "
unique to the device, i.e. if several targets are within the detection range,
the distance to the closest target is measured. The icon that is displayed
by the device in this case is " ".
BRIGHTNESS CONTROL OF THE DISPLAY
The rangefinder has a red OLED display and allows easy reading of the re-
sults even on bright days. There are a total of six brightness levels that can
be selected. To adjust the brightness of the display, the full display mode (V)
must be activated. This mode is accessed by pressing the "M" mode button (F)
repeatedly until all three mode symbols are displayed in the top left corner
of the field of view. The current illumination level appears in the center of the
field of view (VI). To switch between the brightness levels, the switch-on "
" button must be pressed. After the appropriate brightness has been found,
the mode button can be used to return to standard mode "M" and to continue
measuring respectively to switch again to the desired mode.

UNITS OF MEASURE

With the rangefinder, you can choose between yard "Y" or meter "M" (3; 5). To
change the unit of measure of the distance display, the mode button "M" (F)
should be pressed for approx. 2 seconds.
MEASURING SEQUENCE
After the switch-on button " " (E) has been pressed, the circle of the dis-
played target mark "
If the switch-on button is pressed again, the distance of the object is mea-
sured and shown in the display. In the field of view, one can recognize the
activation of the laser by the symbol " " (9) appearing around the circle of
the target.
It should be noted that, for a reliable measurement, the " " button must be
pressed the second time so long until the distance value is displayed (about 2
seconds). If no value is displayed after 3 seconds, the reflection on the object
is too bad and no distance can be measured. If this is the case, the message
"END" appears in the display.

SCAN FUNCTION

Furthermore, the laser rangefinder has a scan function. If the device the unit
is moved while keeping the switch-on button " " pressed, the range and an-
gle measured values are constantly updated. This is possible in all measuring
modes.
16
" will be displayed. If the target is not
" (1) must be aligned with the target object.
