Noblex NF 10x42 R advanced Gebrauchsanleitung Seite 13

Measurement accuracy [°]
Resolution of angle measurement [°]
Operating temperature range [°]
Max. length [mm]
Max. width [mm]
Weight [g]
SCOPE OF SUPPLY
• Case
• Carrying strap
• 1x Battery CR2, 3V
• NOBLEX optics cleaning cloth
• Warranty card
COMPONENTS OF THE DEVICE
A) Battery compartment cap
B) Center joint and focus ring
C) Rotating eyecups
D) Diopter ring
E) Switch-on button
F) Mode button
G) Objective lens and laser receiving channel
H) Laser transmitter channel
START-UP
Inserting and removing the battery
First, unscrew the battery compartment cap (A). If necessary, use a coin as an
aid. Then, a lithium battery CR2 (included in delivery) must be inserted into
the battery compartment, with the minus-side outwards. The service life of
the battery is approx. 2000 measurements.
Interpupillary distance
In order to obtain a large, circular and sharply focused image, the binoculars
must be adjusted to the interpupillary distance of the various users. This cor-
rection is made by bending the binoculars around its central joint (B) until the
two fields of view of the right and left telescopes coincide completely when
viewing an object.
±1.0
0.5
-20 to +40
190
140
980
13
