VEVOR FLO300 Installationsanleitung Seite 5

The water temperature should be a minimum of 1℃ for it is important that
the unit does not freeze, and a maximum water temperature is 90℃.
Input Power Rating:
Input Voltage:
Flow Rated:
Max Horizontal Lift:
(1) Accessories list
Check Valve
(2) Install the check valve at the outlet. Tighten with the snap hoop
(accessory D). Remove the choke plug from the product, install the rubber
tube (accessory B), and tighten it with the snap hoop (accessory C). The
outlet pipe is 3/4" (1" and 1-1/4" are also good choices), and inlet pipes are
1-1/2".
SPECIFICATIONS
350W
220-240V, 50HZ
100L/MIN
70M
INSTALLATION GUIDANCE
Rubber Tube
Max Vertical Lift:
Max Temperature:
Noise Level:
Degree of Protection:
Snap hoop
(32mm-50mm)
- 3 -
7M
90℃
45 dBA
IPX4
Snap hoop
(20mm-32mm)
