3. MOUNTING INSTALLATION
Note: The kit supplied in the package is designed for mounting on a solid wall or ceiling. If mounted onto other
types of walls, you will need appropriate fixings (not supplied). Please make sure the wall or ceiling is safe to
mount. We highly recommend to have the panel installed by a qualified electrician or authorized installer. The
heater must be at least 20 cm removed from all objects, walls, etc.; the distance to the floor must be at least
20 cm.
Step 1.
Use the supplied template
to mark the hole positions
on the wall.
Step 2.
Drill the holes using an
8mm drill bit.
Step 3.
Insert the plugs into the
holes.
Step 4.
Screw the supplied screws
into the wall.
Step 5.
Mount the panel onto the
screws.
Step 6.
Slide the panel to the left,
then down.
MOUNTING TEMPLATE
1
WALL
3
WALL
5
WALL
2
WALL
4
WALL
6
WALL
