ASSEMBLY OF THE ADAP-
TER

1) Assembling the lower adapter

1� Set both sides of the chassis
suspension to "hard�" The suspension
must be set to the same position on
both sides, otherwise, the chassis will
be unevenly loaded and may become
damaged��
2� Fully extend the telescopic handle�
Ensure that the telescopic handle is
extended equally on both sides before
locking it in place� Lock the telescopic
handle with the telescopic locks with a
"click�"
3� Fold down the front side of the basket
at the front wing�
4� Place the lower adapter on the chassis
at the front leg's frontwing, above the
front wheel� Push the adapter down
as far as possible on the plastic part of
the front wing� Ensure the red/green
indicator is facing outward and the
click-in attachment is pointing inward
toward the chassis� Repeat on the other
side�
5� Lock the lower adapter by inserting the
INLINE ADAPTER FOR SENTO MAX / SENTO LUX v.1.0
NOTE!
The images only illustrate the combination with
two seats� All combinations that the Inline Adapter
can be used with and that are shown/described in
this manual are included in these illustrations� The
illustrations also cover the transport of one child
with the Inline Adapter, as well as any additional
accessories (e�g�, Side Bag)�
WARNING
Emmaljunga warns of an increased risk of tipping
when the Inline Adapter is used�
Children are active and can suddenly change the
weight and balance of the stroller� Keep in mind
that on sloping surfaces (this also applies to level
changes such as curbs/steps), the risk of tipping
increases� Never let go of the handlebar!
locking sleeve from underneath into
the adapter until the red marking is
completely covered�
6� The adapter is correctly assembled
when only a green marking is visible in
the indicator window�
7� Attach the metal bar with the two
supplied screws� The bar is designed
to reduce the risk of the stroller tipping
over�
WARNING
• There must be no child in the stroller
when the adapter is being assembled
or when the stroller is folded up or
down
• Avoid having children nearby when
the adapter is being assembled�
• Ensure that children are kept away
from all moving parts if you adjust the
stroller, as they could be injured�
• Never use the adapter if the indicator
shows red�
• Risk of pinching! Be careful when
attaching the adapter to avoid
pinching injuries�
