6.2 Wall assembly
Specifications VESA
Inches
32" 200 x 100 mm
Note:"D" is the effective length of the screw in the mounting hole.
Before installing the wall-mounted bracket,
please screw the 4 wall-mounted adapter studs
into the 4 wall-mounted nuts of the metal back.
The figures and illustrations in this manual are
provided for reference only and may differ from
their actual appearance.
Note:
1. The bracket fixed on the wall is an optional part.
2. When assembling the TV, there should be no other articles
around it and please keep it distant from other articles.
3. When assembling the TV, please ask the professional worker
to fix it in order to avoid danger.
4. The fixing picture is only for reference.
5. Please follow the user's manual about bracket assemble to fix
the TV.
6. Attach the mounting bracket with the VESA compatible wall
mounting kit.
DYON SMART 32 VX V2
(A*B)
Standard screw
(C*D)
M6 x L10
Quantity
4
