EX-1339HMVS
English
5. Hardware Installation
Because there are large differences between PC's, we can give you only a general installation
guide. Please refer your computer's reference manual whenever in doubt.
1. Connect the USB cable (B-Plug) to the USB B-Port at the USB module.
2. Connect the optional power supply to the Terminal Block of the USB module.
3. After them connect the USB cable (A-Plug) to the USB A-Port at your PC.
4. Now set the Dip-switch to the desired mode and termination. (see Switch-Settings)
5. Now you can start you're PC and continue with Software Installation.
6. Software Installation
Windows 2000/ XP/ Vista/ 7/ 8/ Server 200x
Windows will recognize a new „FT232R USB UART" and open the hardware assistant. Please
choose manual installation and put the driver CD into your CD-ROM drive. Enter Path
"D:\USB_to_IO\FTDI\(32_64bit)Win7_8_XP_Vista_2008_2008R2_2003_2000"
into the box for the Path/Source and click at >next/continue<. Now Windows search for the drivers
in the specified directory. Follow the hardware assistant and finish the installation. If Windows
recognizes other new devices repeat the above described steps. Attention! Restart Windows in
any case after installing the drivers.
CHECK THE INSTALLED DRIVER
Click at Start<>Run< then enter "compmgmt.msc" and click at >OK<. In the windows that open
select >Device Manager<. Under "Ports (COM and LPT)" you should find some new entry's, for
example „USB Serial Port (COM3)". If you see this or similar entries the module is installed
correctly.
CHANGE PORT NUMBER (NOT WIN98 & ME)
If you like to change the port number for example COM3 to COM5, open the >Device Manager< click
at >COM3<, >Settings< and then >Advance<. There you can choose between COM3 up to
COM256.
Windows 98/ 98SE/ ME
Windows will recognize a new "FT232R USB UART" and open the hardware assistant. Please
choose manual installation and put the driver CD into your CD-Rom drive (as sample D:). Now
enter the Path "D:\USB_to_IO\FTDI\Win98_ME" into the box for the Path/Source and click at
>next/continue<. Now Windows search for the drivers in the specified directory. Follow the
hardware assistant and finish the installation. If Windows recognizes other new devices repeat the
above described steps.
Attention! Restart Windows in any case after installing the drivers.
17
