CONDTROL HYDRO PRO Bedienungsanleitung Seite 3

WOOD AND CONCRETE
EN
MOISTURE METER
Congratulations on your purchase of the wood and concrete moisture meter
HYDRO PRO CONDTROL.
Safety instructions provided in this user manual should be carefully read before
using the product for the first time.
SAFETY REGULATIONS
Attention! This user manual is an essential part of this product.
The user manual should be read carefully before you use the product for the first
time. If the product is given to someone for temporary use, be sure to enclose
user manual to it.
- Do not misuse the product
- Store the product beyond reach of children and unauthorized people.
- It is prohibited to disassemble or repair the product yourself. Entrust product
repair to qualified personnel and use original spare parts only.
- Do not use the product in explosive environment, close to flammable materials.
- Avoid heating the batteries to avoid the risk of explosion and electrolyte
leakage. In case of liquid contact with skin, wash it immediately with soap and
water. In case of contact with eyes, flush with clean water during 10 minutes and
consult a doctor.
FUNCTIONS/APPLICATIONS
HYDRO PRO CONDTROL is designed for effective control of humidity in
various types of wood and concrete. The principle of operation is based on the
dielcometric method of measuring humidity, namely, on the correlation of the
dielectric constant of the material between the moisture content at positive
temperatures.
While interaction with the measured material, the capacitive converter generates
a signal proportional to the dielectric constant, which is registered by the
measuring unit and converted into a humidity value. The measurement results
are displayed on the display screen.
Available types of controlled materials:
8 groups-wood
4 groups - concrete (light, heavy).
A table of materials is in Appendix No. 1;
The main application field: various types of wood processing, as well as
construction and technology, where the moisture content of materials is
regulated by normative-technical or technological documentation.
4
All manuals and user guides at all-guides.com
HYDRO PRO CONDTROL
User manual
WOOD AND CONCRETE
EN
MOISTURE METER
Thanks to the remote sensor* HYDRO PRO CONDTROL has the ability to measure
relative humidity and air temperature, dew point and equilibrium moisture of
wood.
* -not included in the delivery package
DELIVERY PACKAGE
1. Moisture meter – 1 pc.
2. Pouch with a strap – 1 pc.
3. User manual – 1 pc.
4. Battery (ААА) – 3 pcs.
5. Micro-USB charger – 1 pc.
TECHNICAL SPECIFICATIONS
Humidity measuring range
Wood and woodworks (420-700 kg/m
Gypsum 1400 kg/m
3
Screed (cement-sand) 1700 kg/m
3
Concrete 1800 kg/m
3
Concrete 2000 kg/m
3
Concrete 2200 kg/m
3
Concrete 2400 kg/m
3
Limits of permissible absolute accuracy of moisture
meter when measuring humidity:
Wood and woodworks
In the range of 2% to 12%
In the range of 12% to 35%
In the range of 35% to 65%
Gypsum 1400 kg/m
3
Screed (cement-sand) kg/m 3
Concrete 1800 kg/m
3
Concrete 2000 kg/m 3
Concrete 2200 kg/m
3
Concrete 2400 kg/m 3
Single measurement runtime, с, max.
Internal memory
HYDRO PRO CONDTROL
User manual
) 2.0-65.0%
3
0.1-35.0%
0.1-35.0%
0.1-35.0%
0.1-35.0%
0.1-20.0%
0.1-10.0%
±1.5%
±3.0%
Not rated
±1.5%
±1.5%
±1.5%
±1.5%
±0.9%
±0.9%
≤1 sec
50 values
5
