an electrical outlet; therefore, they are always in operating
condition. To prevent serious personal injury, take extra
precautions and care when performing maintenance, service
or for changing the cutting attachment or other attachments.
WARNING:
To prevent serious personal injury, remove
the battery pack from the power head and wait for the brush
roller stop before servicing, cleaning, changing add-on
attachments or when the product is not in use.
GENERAL MAINTENANCE
WARNING:
Do not at any time let brake fluids,
gasoline, petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can damage,
weaken, or destroy plastic, which may result in serious
personal injury.
WARNING:
When cleaning the bristle brush
attachment, DO NOT immerse it in water or other liquids. Do
not clean your machine with a pressure washer. The solid jet
of water may damage parts of the machine.
BRUSH ROLLER MAINTENCE
◾
Clean the brush roller frequently.
◾
If any of the brush roller needs replacing due to damage,
replace both brush rollers for best performance.
All bristle brush service, other than the items listed in these
maintenance instructions, should be performed by authorized
service personnel.
REPLACING THE BRUSH ROLLERS
WARNING:
A damaged brush roller may break into
pieces after long-time use, which may cause dangerous
projectiles. Thrown objects can cause serious injury. Inspect
it regularly and do not operate the bristle brush with worn or
damaged parts.
To Remove (Fig. L)
1. Remove the hitch pin from the end of the drive axle.
2. Pull the brush roller, together with cover plate on it,
off the drive axle.
3. If the drive axle is damaged, remove the lock pin
from the hole of the drive axle and pull the drive axle
off the driven shaft (Fig. M).
4. If the cover plate is damaged, pull it from the brush
roller and replace it.
5. Follow the same steps to remove the other brush roller.
Fig. L parts description see below:
L-1 Driven Shaft
L-2 Lock Pin
To Install
1. Install the drive axle onto the driven shaft and insert
2. Install the cover plate onto the brush roller with the
3. Push the brush roller onto the drive axle (see Fig. G).
4. Insert the hitch pin in the hole at the end of the drive
5. Follow the same steps to mount the other brush
same time.
CLEAN THE UNIT
◾
◾
◾
STORING THE UNIT
◾
◾
◾
◾
Protecting the environment
L-4 Hitch Pin
L-5 Cover Plate
BRISTLE BRUSH ATTACHMENT — BBA2100
L-3 Brush Roller L-6 Drive Axle
the lock pin into the hole on the drive axle (see Fig. F).
rib in the cover plate aligned with the hole on the
brush roller (Fig. N).
Fig. N parts description see below:
N-1 Hole
N-2 Rib
axle and fold it flat.
roller.
WARNING:
Always replace both brush rollers at the
Remove the battery.
Clear the pieces of roots, clogged soils, or plants from
the brush rollers, guard, or the gear box. For thorough
cleaning, remove the brush rollers and guard to wash
them thoroughly. For detailed replacement steps please
see above section"REPLACING THE BRUSH ROLLERS".
Keep the air vents free of obstructions.
Remove the battery pack from the tool.
Clean the tool thoroughly and inspect the brush rollers.
Remove the bristle brush attachment from the power
head and cover the attachment shaft with end cap to
avoid dirt getting into the coupling.
Store the tool in a dry, well-ventilated area, locked-up
or up high, out of the reach of children. Do not store
the unit on or adjacent to fertilizers, gasoline, or other
chemicals.
Do not dispose of electrical equipment,
used battery and charger into household
waste! Take this product to an authorized
recycler and make it available for separate
collection. Electric machines must be
returned to an environmentally compatible
recycling facility.
