EUROLITE IR-38 remote control
The IR remote control has the following functions:
_
+
OFF
FAV FAV FAV
1 2 3
FADE
STROBE COLOR
JUMP
FLASH
WHITE
*
Preset color
R< 255 >,B < 255
Preset color
G<255>,B <255>,
Preset color
R<255>,B <255>
Preset color
R<255>,G<255>
Notes:
• When actuating a button, always direct the remote control towards the sensor. There must be no obstacles
between remote control and the sensor. When CRMX is activated (ON), the remote control functions are
deactivated.
• The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage. Prior to the first operation remove the
foil from the battery support on the rear side of the remote control. Otherwise operation of the remote
control is not possible.
• If the range of the remote control decreases, replace the battery. For this purpose,
on the rear side of the remote control press the small bar with the groove to the
right and at the same time remove the battery support. For operation, one 3 V
button cell type CR 2032 is required. When inserting, pay attention that the
positive pole of the button cell shows upwards in the support.
• Remove the battery from the remote control as a precaution if the device is not used for a longer period of
time.
Buttons
ON
OFF
Pty1
Pty2
+
Pty3
Pty4
CC
FAV
1
>
Function
IR remote control
ON
on/off
_
Dimmer intensity of the LED colors /
stepless RGBW color mixture, brightness with
+ and -
Preset colors*,
brightness with + and -
F
avorite color setting - press one of the 3 buttons
FAV FAV
2 3
Internal program Pty 1,
Pty1
Switching colors, speed with + and -
Internal program Pty 2,
Pty2
Switching colors, speed with + and -
Internal program Pty 3,
Pty3
Switching colors, speed with + and -
Internal program Pty 4,
Pty4
Switching colors, speed with + and -
Switching through preset colors 01-37,
CC
brightness with + and -.
Fade/Jump
FADE
JUMP
Switching internal programs
Pty1-Pty4
Strobe effect only for white,
STROBE
WHITE
speed with + and -
A second press ends the strobe effect.
Strobe effect 12 colors,
speed with + and -
COLOR
FLASH
A second press ends the strobe effect.
