PARTS LIST
6
5
12
1. Handle
2. Canopy
3. Sun cap
4. Shoulder pads
5. 5-point harness
6. Bumper bar
7. Bumper bar release button
8. Footrest adjustment button
9. Folding button
10. Storage basket
(max weight 3 kg)
2
1
3
4
7
8
9
10
11
1. Chassis
2. Front Wheels (x2)
3. Rear Wheels (x2)
4. Seat unit
5. Back Seat Adapters
6. Front Seat Adapters
15
16
17
1 3
1
11. Front wheels
12. Front wheel release button
13. Front swivel wheel lock
14. Handle height adjustment button
15. Canopy latch
16. Seat adjustment release button
17. Seat release button
18. Rear wheels
19. Parking brake
20. Rear wheel release button
20
8
UK
14
19
7
