Vorbereitung
3 Assembly and Set-Up
For detailed installa�on steps, please refer to the installa�on video on the
product page on Amazon.
Führen Sie die Schnellspannerschraube mit der Beilagscheibe
durch die Lenkstangenhalterung, den Verriegelungsclip des
Faltmechanismus und befestigen Sie sie mit der Mutter.
1.Loosen the screw and remove the upper block,
quick release screw, gasket and belt buckle.
2-2.Put the handlebar screw through the gasket,
upper block, lower block, belt buckle, and gasket
Schließen Sie den Schnellspanner und stellen Sie sicher, dass
in turn, and then �ghten with nuts.
Note: Do not over�ghten the screw.
er gut sitzt.
Make sure the screw is �ghtened just enough to
allow the latch to snap down.
05
Ziehen Sie die Mutter am Schnellspanner nicht zu fest an.
Der Schnellspanner muss sich mit spürbarem Widerstand
öffnen und schließen lassen.
10
1.Loosen the screw and remove the upper block,
quick release screw, gasket and belt buckle.
2-2.Put the handlebar screw through the gasket,
upper block, lower block, belt buckle, and gasket
in turn, and then �ghten with nuts.
Note: Do not over�ghten the screw.
Make sure the screw is �ghtened just enough to
allow the latch to snap down.
2-1.Center the handle on the lower block, align the
upper block with the slide rail of the lower block,
and slide it in.
05
3. Snap down the latch in the middle of the
handlebar to secure.
ACHTUNG!
2-1.Center the handle on the lower block, align the
upper block with the slide rail of the lower block,
and slide it in.
3. Snap down the latch in the middle of the
handlebar to secure.
4.Remove the screw from the bell and a�
bell to the handlebar.
6. To adjust the height of the handleb
the quick-release lever and slide theT
desired posi�on and resecure the qui
lever to lock into place.
Note: The T-bar has a 5.9 inch adjust
range. Please do not adjust the heigh
the range, otherwise there is a risk o
breakage.
