SETUP
1
Screw on the antenna provided to the antenna input and put it in a
vertical position.
2
Connect the transmitter to the DMX controller and the receiver to the
DMX input of the first DMX-controlled unit in the chain. Connect a
120 Ω terminating plug to the DMX output of the last DMX unit in the
chain. Alternatively, provide each DMX-controlled unit with its
individual receiver to avoid cabling between the DMX units.
3
Set each transmitter and receiver into operation by connecting its
power unit to the power input and the mains plug to a mains outlet
(100-240 V~, 50/60 Hz).
The status indicator shortly flashes red, green and blue. Afterward, it
lights permanently according to the selected transmission channel.
4
Set each transmitter and receiver to the same transmission channel
by pressing the side button on the devices.
The selected transmission channel is indicated by the status indicator.
Channel
1
2
3
4
5
6
Thus, the wireless DMX network is set up and the receivers are paired
to the transmitter. The assignment of the receivers to the transmitter is
kept memorized even after disconnecting the power supply.
5
As soon as the transmitter receives a DMX signal, the status indicator
switches to red. Shortly afterward, the status indicators of the
receivers start flashing green to indicate that the DMX signal is being
received. The DMX-controlled units can now be controlled via radio.
6
After the operation, disconnect the mains plug of the power supply unit
from the mains outlet, to prevent unnecessary power consumption.
www.eurolite.de
Color
Red
Green
Blue
Yellow
Turquoise
Purple
