4-fold DMX splitter for truss mounting
No. 70064811
USER MANUAL
EN
Welcome to Eurolite! This compact 4-fold splitter is designed for reliable distribution of
DMX512 signals in rigs. The unit features 3-pin XLR connectors with status indicators,
and a M10 threaded insert for truss attachment. Delivery includes a power cord.
SAFETY WARNINGS
Please read these instructions carefully before using the product. They contain
important information for the correct use of your product. Please keep them for future
reference.
Intended use
This product distributes control signals. It is intended for commercial use.
Ÿ
Only use the product according to the instructions given herein. Damages due to
Ÿ
failure to follow these operating instructions will void the warranty! We do not
assume any liability for any resulting damage.
We do not assume any liability for material and personal damage caused by
Ÿ
improper use or non-compliance with the safety instructions. In such cases, the
warranty/guarantee will be null and void.
Unauthorized rebuilds or modifications of the product are not permitted for reasons
Ÿ
of safety and render the warranty invalid.
Danger due to electricity
The product is suitable for indoor use only. Do not use it outdoors. Never expose it to
Ÿ
rain or moisture. Do not store it in rooms exposed to moisture.
The product is supplied with hazardous mains voltage. To reduce the risk of electric
Ÿ
shock, do not open any part of the product. There are no serviceable parts inside the
device.
Only connect the device to a properly installed mains outlet. The outlet must be
Ÿ
protected by residual current breaker (RCD). The voltage and frequency must
exactly be the same as stated on the device. If the mains cable is equipped with an
earthing contact, then it must be connected to an outlet with a protective ground.
Never defeat the protective ground of a mains cable. Failure to do so could result in
damage to the device and possibly injure the user.
The mains outlet must be easily accessible so that you can unplug the device
Ÿ
quickly if need be.
Never touch the mains plug with wet or damp hands. There is the risk of potentially
Ÿ
fatal electric shock.
The mains cable must not be bent or squeezed. Keep it away from hot surfaces or
Ÿ
sharp edges.
Never pull the mains cable to disconnect the mains plug from the mains outlet,
Ÿ
always seize the plug.
Unplug the device during lighting storms, when unused for long periods of time or
Ÿ
before cleaning.
Do not expose the device to any high temperatures, direct sunlight, dripping or
Ÿ
splashing water, strong vibrations or heavy mechanical stress.
Do not place any objects filled with liquids on the device.
Ÿ
Do not place any open sources of fire, such as burning candles, on or directly next to
Ÿ
the device.
If the fine-wire fuse of the device fuses, only replace it by a fuse of same type and
Ÿ
rating. Disconnect the device from the power supply first.
Make sure that objects cannot fall into the device, in particular metal parts.
Ÿ
Only have repairs to the device carried out by qualified service personnel. Repairs
Ÿ
are required when the device is visibly damaged, liquid has been spilled or objects
have fallen into the device; when the device has been exposed to rain or moisture,
has been dropped or malfunctions occur.
Eurolite is a brand of Steinigke Showtechnic GmbH • Andreas-Bauer-Str. 5 • 97297 Waldbüttelbrunn, Germany
Danger to children and people with restricted abilities
This product is not a toy. Keep it out of the reach of children and pets. Do not leave
Ÿ
packaging material lying around carelessly.
This device may be used only by persons with sufficient physical, sensorial, and
Ÿ
intellectual abilities and having corresponding knowledge and experience. Other
persons may use this device only if they are supervised or instructed by a person
who is responsible for their safety.
Warning – risk of injuries
Make sure that the product is set up or installed safely and expertly and prevented
Ÿ
from falling down. Comply with the standards and rules that apply in your country.
For commercial use the country-specific accident prevention regulations of the
Ÿ
government safety organization for electrical facilities must be complied with at all
times.
If you lack the qualification, do not attempt the installation yourself, but instead use a
Ÿ
professional installer. Improper installation can result in bodily injury and or damage
to property.
The manufacturer cannot be made liable for damages caused by incorrect
Ÿ
installations or insufficient safety precautions.
For overhead use, always secure the device with a secondary safety attachment
Ÿ
such as a safety bond or safety net.
Make sure that the area below the installation place is blocked when rigging,
Ÿ
derigging or servicing the device.
Cleaning and maintenance
Cleaning of the device is limited to the surface. Only wipe off the product with a soft
Ÿ
lint-free and moistened cloth. Never use solvents or aggressive detergents.
Disconnect the device from power and allow it to cool before cleaning.
There are no serviceable parts inside. Do not open the housing. Do not try to repair
Ÿ
the device by yourself as this may result in damage.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type
and rating.
1 Disconnect the device from power and allow it to cool.
2 Open the fuse holder of the mains connection with a fitting screwdriver.
3 Remove the old fuse from the fuse holder and replace it with a new fuse.
4 Carefully push the fuse holder back into its position before reapplying power.
PROTECTING THE ENVIRONMENT
When to be definitively put out of operation, take the product to a local recycling
plant for a disposal which is not harmful to the environment. Devices marked
with this symbol must not be disposed of as household waste. Contact your
retailer or local authorities for more information.
TECHNICAL SPECIFICATIONS
Power supply: ................. 100-240 V AC, 50/60 Hz / 1.5 W
DMX connectors:.............3-pin XLR (pin 1: ground, pin 2: signal -, pin 3: signal +)
Power connectors:.........P-Con IN (blue), OUT (gray) max. 10A
Dimensions (Wx D x H):.... 9 x 9.5 x 14 cm
Weight: ...........................900 g
Subject to change.
www.eurolite.de
Publ. 10/2024
