EN
CLEANING THE SPRAY ARMS
The Top Rack has a fixed wash tube with all the wash nozzles facing up-
ward. To clean it you can slide the rack out and with a tweezer remove items
that may be lodged in the nozzles.
TROUBLESHOOTING
In case your dishwasher doesn't work properly, check if the problem can be solved by going through the following list. For other errors or is-
sues please contact authorized After-sales Service whose contact details can be found in the warranty booklet. Spare parts will be available
for a period of either up to 7 or up to 10 years, according to the specific Regulation requirements.
PROBLEMS
POSSIBLE CAUSES
Descale
indicator is lit
Limescale is accumulating on internal components
or blinking;"dES"
of the appliance.
alarm is displayed.
The filter is clogged with food residues or
The dishwasher
limescale
won't drain.
Display shows:
The drain hose is kinked.
F7 E3 or F9 E1
The sink drain pipe is blocked.
The dishwasher
No water in the water supply or the tap is closed. Make sure there is water in the water supply and the water tap is open.
does not fill the
The water inlet hose is kinked.
water. The display
shows: H 2 O and
The screen in the water inlet hose is clogged; it is
is lit; acoustic alarm
necessary to clean it.
sounds.
The filter is clogged with food residues or
limescale.
The dishwasher
Drain hose positioned too low or siphoning into
finishes the cycle
the home sewage system.
prematurely.
The display shows:
F8 E3
An excessive amount of foam is present.
Air in the water supply.
Rinse aid is not present or the dosage is too low.
The dishes have been unloaded after the door
was opened automatically but before the actual
cycle end.
The dishes are not
dried well.
The dishes are sitting too flat.
The selected cycle does not have the drying
phase.
The dishes are made of non-stick or plastic.
The salt reservoir is empty.
Dishes and glasses
The water hardness setting is too low.
are covered with
limescale or a whit-
The cap of the salt reservoir is not properly closed. Check and close the salt reservoir cap.
ish film.
The rinse aid reservoir is empty or the rinse aid
dosage is insufficient.
The dishwasher
Valve is blocked or faulty.
shows F8 E5
Depends on the liquid detergent used and
Detergent leaks.
can be emphasized in case of delay option is
activated.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.whirlpool.eu/docs and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet).
When contacting our After-sales Service, please state the codes provided on your product's identification plate.
The model information can be retrieved using the QR-Code reported in the energy label.
The label also includes the model identifier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
®/TM/ © 2024 Whirlpool, Produced under license
4
On occasions, food residue
may become encrusted onto
the spray arms and block the
holes used to spray the water. It
is therefore recommended that
you check the arms from time
to time and clean them with
a small non-metallic brush.
To remove the upper spray you
must remove it together with
the manifold.
Please scan the QR code on your product in order to have more detailed information.
SOLUTIONS
Descale the appliance immediately using the Self Clean program and a commercially available
descaling product (see OPTIONS AND FUNCTIONS). Refill the reservoir with salt. Check the water
hardness setting. If the appliance is not descaled, it will stop functioning.
Clean the filter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
Check the drain hose (see INSTALLATION INSTRUCTION).
Clean the sink drain pipe.
Check the inlet hose (see INSTALLATION). Open dishwasher door, press START/Pause button and
close the door within 4 seconds.
Check and clean the screen in the water inlet hose. Open dishwasher door, press START/Pause
button and close the door within 4 seconds.
Clean the filter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
Check if the end of the drain hose is placed at the correct height (see INSTALLATION). Check for
siphoning into the home sewage system, and install a siphon breaker/air admittance valve if
necessary.
The detergent has not been measured out correctly or it is not suitable for use in dishwashers
(see FILLING THE DETERGENT DISPENSER).
Check water supply for leaks or other issues letting air inside.
Make sure the rinse aid dispenser is filled (see FILLING THE RINSE AID DISPENSER). Multifunctional
tablets only will not provide as good drying effects as the actual use of liquid rinse aid.
Make sure the cycle has ended before starting to unload the dishes (see DAILY USE). For even
better drying results, it is recommended to let the dishes sit inside the dishwasher with the door
open for additional 15 minutes after the cycle ends.
If you notice puddles of water inside cavities of cups, mugs or bowls, try loading the dishes (es-
pecially in the upper rack) providing more inclination to let larger amounts of water drip down
before drying starts.
Please check in the PROGRAMS TABLE if the selected program is equipped in the drying phase.
A cycle without the drying phase may not deliver desired drying efficiency, so it is recommend-
ed to change cycle selection for the one that has the drying phase.
Some water drops remaining on this type of material are normal.
Refill the reservoir with salt as soon as possible. Using the appliance without salt may cause
damage to its internal components.
Increase the setting (see WATER HARDNESS TABLE).
Refill the dispenser with rinse aid and check the dosage setting (for more information - see
FILLING THE RINSE AID DISPENSER).
Close the water tap, if possible. Do not switch off the power supply. Call the service.
Small leaks will not cause machine malfunction and can be avoided by changing liquid deter-
gent type or using tablets.
Quick Guide
The lower spray arm may be removed by
pulling it upwards and rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it down and rotating it
clockwise.
The top spray arm may be removed by
pressing it up and then rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it upwards and rotating
it clockwise.
:
IEC 436
