Quick Guide
INTERNAL LIGHTS - When the feature is active the LEDs in the tub are
automatically switched on/off as soon as the user open/close the door
respectively. If the door remains opened for more than 10 min, the LEDs in the
tub switch off (to turn them on again, the door has to be closed and opened
again). This feature is active by default, but it is possible to deactivate it in
the "SETTINGS MENU".
SENSING - When the sensor is detecting the soil level an
animation appears in the display (around 20 min.) and the cycle
duration is updated. SENSING is for the level of soiling on the
dishes and is present for all cycles (excepting Eco) adjusting the program
accordingly.
LOADING THE RACKS
TOP RACK
The top rack pro-
vides a targeted
cleaning Wash Zone
for bowls, mugs,
even big plates and
cutlery that you'd
normally load in the
lower racks, making
extra space for the rest of the day's dishes.
A separate arrangement of the cutlery makes
collection easier after washing and improves
washing and drying performance.
Knives and other utensils with sharp edges
must be positioned with the blades facing
downwards.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: a high po-
sition to place bulky crockery in the lower basket and
a low position to make the most of the tip-up supports
by creating more space upwards and avoiding collision
with the items loaded into the lower rack.
We strongly recommend that you do not adjust the
height of the rack when it is loaded. NEVER raise or
lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable flaps can be folded or unfolded to opti-
mize the arrangement of crockery inside the rack. Wine
glasses can be placed safely in the foldable flaps by insert-
ing the stem of each glass into the corresponding slots.
CARE AND MAINTENANCE
CLEANING THE FILTER ASSEMBLY
A
1
B
C
A
2 3
CYCLE COUNTER - This feature shows the number of cycles the
dishwasher has performed.
For the number of cycles from 0-999, a fixed number will be displayed.
Example for 25 cycles.
When the cycle number is higher than 1000, the number will scroll in
the display. The "_" represents the ".", as for instance: 1.000 = 1_000,
13.947= 13_947 (the number will scroll for 3 times).
After the cycle visualization, the display will return to visualize „
NOTE: The dishwasher may have already performed about 30 cycles.
This is due to the extended quality process carried out during
production. It guarantees higher product quality.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large
plates and lids should ideally be placed at the
sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can
be used in a vertical position when arranging
plates or in a horizontal position (lower) to load
pans and salad bowls easily.
(loading example for the lower rack)
POWER CLEAN®
Power Clean® uses the special water jets in the
rear of cavity to wash more intensively the high
dirty items. The lower rack has a Space Zone,
a special pull-out support in the rear of the rack
that can be used to support frying pans or baking pans in upright position,
thus taking up less space. Placing the pots/casseroles faced to the Power
Clean® component please activate the POWER CLEAN® on the panel.
CUTLERY BASKET
It is fitted with top grids for improved cutlery arrangement.
It must only be positioned at the front of the lower rack.
Knives and other utensils with sharp edges must be
placed in the cutlery basket with the points facing
downwards or they must be positioned horizontally
in the tip-up compartments on the upper rack.
More information in the Daily Reference Guide on website.
The dishwasher must not be used without fil-
ters or if the filter is loose.
It is important when reinstalling the filter that
the two triangles shown on the zoom meet (Fig 1).
In case you find foreign objects (such as broken
glass, porcelain, bones, fruit seeds etc.) please re-
move them carefully.
Inspect the trap and remove any food residues.
NEVER REMOVE the wash-cycle pump protec-
tion (shown by an arrow) (Fig 4).
4
Example for
13.947 cycles:
CAPACITY: 15 standard place-settings
EN
".
3
