6. Initial Operation
6.1 Safety guard
Turn the safety guard until the closed section
is facing the operator.
For safety reasons, only use the guard
provided for the respective accessory! Using
an incorrect guard can lead to loss of control and
serious injuries. See also chapter 11. Accessories!
See figure, page 2.
Safety guard for grinding (2)
Designed for work with roughing wheels, flap
sanding pads, diamond cutting discs, wire brushes.
Attach safety guard for separating / cut-off
guard clip (12)
Designed for work with cutting discs and diamond
cutting discs.
For safety reasons always attach the cut-off
guard clip (12) when performing cutting work.
Do not use a damaged cut-off guard clip. Before
use, check for cracks, deformations or signs of
severe wear and tear.
Fitting
Push the cut-off guard clip (12) onto the safety
guard (2) of the angle grinder as shown. The cut-off
guard clip must engage on the safety guard with
both latching hooks (13), until you hear a "click".
Do not forget the accessories when replacing the
fixed guard.
Removal
Bend one of the two latching hooks (13) a bit and
carefully until the latching hook (13) does not
protrude anymore from the guard rim. Then pull off
the cut-off guard clip and put aside.
6.2 Battery pack
Charge the battery pack (10) before use.
Recharge the battery pack if performance
diminishes.
The ideal storage temperature is between 10°C and
30°C.
Battery packs have a capacity and signal display (8)
(depends on design variant):
- Press the button (9), the LEDs indicate the charge
level.
- The battery pack is almost flat and must be
recharged if one LED is flashing.
6.3 Removing and inserting the battery pack
Hold the machine when removing and
inserting the battery pack so that the on/off
switch cannot be unintentionally pressed.
Removal:
Press the battery pack release (6) button and pull
the battery pack (10) upwards.
Inserting:
Slide in the battery pack (10) until it engages.
7. Attaching, removing the
grinding disc
Prior to any conversion work: remove battery
pack from machine. The machine must be
switched off and the spindle at a standstill.
When working with cutting discs, fit the cut-off
guard clip (12) (see chapter 6.1 ) .
7.1 Attaching the grinding wheel
Move the spindle locking button (3) only when
the motor is at a standstill.
See figure, page 2.
1. Locking the spindle: Move the spindle locking
button (3) in position
(11) by hand until the spindle locking clearly
engages.
2. Placing the grinding wheel in position:
Place the grinding wheel on the support flange
(11).
The grinding wheel must lay flat on the support
flange (11) .
3. Securing the fixing screw:
Fit the fixing screw (1)and firmly tighten with
hexagon wrench (7). Remove the hexagon
wrench again and place into the wrench storage
(7).
4. Release the spindle lock:
Move the spindle lock button (3) in position
7.2 Removing the grinding disc
1. Locking the spindle: Move the spindle locking
button (3) in position
(11) by hand until the spindle locking clearly
engages.
2. Removing the fixing screw:
Remove the fixing screw (1) with hexagon
wrench (7) and remove.
3. Removing the grinding disc.
4. Release the spindle lock:
Move the spindle lock button (3) in position
8. Use
8.1 Switching on and off
Check that the spindle lock button (3) is in
position .
Switch on first, then guide the accessory
towards the workpiece.
The machine must not be allowed to draw in
additional dust and shavings. When switching
the machine on and off and keep it away from dust
deposits. After switching off the machine, only set it
down when the motor has come to a standstill.
Avoid switching on the machine accidentally:
always switch it off when the battery pack is
removed from the machine.
ENGLISH en
Use only accessories that
are covered by at least 3.4
mm by the safety guard.
and turn support flange
and turn support flange
.
.
