Back Panel; Installation Requirements - Fs S5800-48Mbq Schnellstartanleitung

LEDs State
Green
Blinking Green
Amber
RJ45
Blinking Amber
O
Green
Blinking Green
QSFP+ Amber
Blinking Amber
O
Green
Blinking Green
SFP28 Amber
Blinking Amber
O

Back Panel

Hot-Swappable Fans

Installation Requirements

Before you begin the installation, make sure that you have the
following:
Phillips screwdriver.
M6 Screws.
Standard-sized, 19" wide rack with a minimum of 1U height available.
Description
The port is linked at 2.5G.
The port is receiving or transmitting packets at 2.5G.
The port is linked at 100M/1000M.
The port is receiving or transmitting packets at 100M/
1000M.
The port is not linked.
The port is linked at 40G.
The port is receiving or transmitting packets at 40G.
The port is linked at 10G.
The port is receiving or transmitting packets at 10G.
The port is not linked.
The port is linked at 25G.
The port is receiving or transmitting packets at 25G.
The port is linked at 10G.
The port is receiving or transmitting packets at 10G.
The port is not linked.
Grounding Point
Hot-Swappable Power Supplies
