• DMX Mode
DMX512 Connection
Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side
to the male 3-pin XLR input of the VDPL304LF. Multiple VDPL304LFs can be linked through serial
linking. The linking cable should be a two-core screened cable with XLR input and output connectors.
DMX512 Chain with Termination
A DMX terminator is recommended for installations where the DMX cable has
to run a long distance or is in an electrically noisy environment (e.g. discos).
The terminator prevents corruption of the digital control signal by electrical
noise. The DMX terminator is simply an XLR plug with a 120 Ω resistor
between pins 2 and 3, which is then plugged into the XLR output socket of
the last device in the chain.
Please see illustrations.
DMX Start Address
All DMX-controlled devices need a digital start address so that the correct device responds to the
signals. This start address is the channel number from which the device starts to "listen" to the DMX
controller. Enter the correct number and read it from the display located on the base of the
VDPL304LF.
You can use the same starting address for a whole group of devices or enter an individual one for
every device.
When all devices have the same address, all the VDPL304LFs will "listen" to the control signal on
one particular channel. In other words: changing the settings of one channel will affect all devices
simultaneously. If you set different addresses, each device will "listen" to a separate channel
number. Changing the settings of one channel will only affect the device in question.
In the case of the 7-channel VDPL304LF, you will have to set the start address of the first
VDPL304LF to 1, the second VDPL304LF to 8 (1 + 7), the third to 15 (8 + 7) and so on.
Detailed DMX Values per Channel
Control Channel 1 – Mode
Value
0
51
52
102
103
153
154
204
205
255
Control Channel 2 – Gobos
When channel 1 in mode 1
Four-output synchronous gobos
Value
0
15
16
30
31
45
46
60
61
75
76
90
91
105
106
120
121
135
136
150
151
165
VDPL304LF
All manuals and user guides at all-guides.com
Description
Spin gobo 1
Spin gobo 2
Spin gobo 3
Spin gobo 4
Spin gobo 5
Spin gobo 6
Spin gobo 7
Spin gobo 8
Spin gobo 9
Spin gobo 10
Spin gobo 11
5
Description
Mode 1
Mode 2
Mode 3
Mode 4
Mode 5
When channel 1 in mode 2
Four-output assembled gobos
Value
0
18
19
36
37
54
55
72
73
90
91
108
109
126
127
144
145
162
163
180
181
198
Description
Spin gobo 1
Spin gobo 2
Spin gobo 3
Spin gobo 4
Spin gobo 5
Spin gobo 6
Spin gobo 7
Spin gobo 8
Spin gobo 9
Spin gobo 10
Spin gobo 11
HQPOWER™
