HQ Power QUAD SPINNER Bedienungsanleitung Seite 4

5. safety eyelet
6. DMX output
7. DMX input
8. power supply input
9. power output
10. fuse holder
11. microphone volume adjustment button
12. MODE button
13. UP button
14. DOWN button
15. control panel
16. remote controller input
7. Use
Switch on your VDPL304LF by connecting it to the mains. After connection the VDPL304LF will
reset and the motors will be trimmed.
Press MODE to enter the mode menu and select the desired mode with UP or DOWN. Following
modes are available:
DMX mode address setting
auto mode
sound-controlled mode
master mode
slave mode
• Auto Mode
Select the mode on the device. Your VDPL304LF will automatically run the built-in effects.
You can also manually change the gobos using the optional VDPL304LF/RC remote controller.
Connect the controller to VDPL304LF through the remote controller input.
• Sound-Controlled Mode
Select the mode on the device. The device is sound-controlled through the built-in
microphone. A separate controller is not required.
• Master/Slave Mode
Connect your VDPL304LFs to the master VDPL304LF. Select the
and the mode on the slave device. All slave devices will now act synchronously to the master
device.
VDPL304LF
All manuals and user guides at all-guides.com
4
mode on the master device
