coated M8x30 bolts on either side.
4. If no accessories are used, the 4 plug-in holes
van be closed with the plastic caps supplied.
Sol+Luna has 5 positions.
Recliner cushion - p10
1. Position the recliner cushion on the sunbed
and attach it to the batyline with the loops on
the underside of the recliner. Note that the loop
closest to the middle needs needs to be at the
head end.
Bolster pillow set - p11
1. You can use the bolster cushions as an armrest
on the sofa. Because of the weights in the
cushions, they will not fall off.
2. Tie the bolster cushions together with the help of
the buttons to use them as a headrest. Position
the whole thing over the headrest, as shown in
the drawing. You can adjust the height by hanging
it higher or lower.
Wheels - p12
1. First, loosen the bolt from the wheels.
2. Slide the wheels over the legs on the desired side
of the lounger. Make sure that both the wheels
and the legs touch the ground and that they are
perfectly upright, parallel to the sunbed.
3. Now tighten the bolts.
4. Now when you raise the lounger, the legs are
off the ground, and you can roll the lounger
wherever you want.
Locker - p14
1. Slide the upper edge of the keder into the highest
groove of the backrest as shown in the drawing.
2. Now position the backrest between the two leg
supports and attach it with 2 pre-coated M8x30
bolts on either side. You will find a small lock in
the locker: see the instructions on the packaging.
Storage net - p15
1. Slide the upper edge of the keder into the middle
groove of the backrest as shown in the diagram.
Please note: Make sure the pouch is on the same
side as the sunbed.
2. Position the storage net in the middle of the
sunbed and then slide the fibreglass rod provided
into the lowest loop.
3. Now position the backrest between the two leg
supports and attach it with 2 pre-coated M8x30
bolts on either side.
4. Next attach the storage net to the underside of
the frame, by pushing the fibreglass rod through
the hole on one side first before you push it
through the hole on the other side. Then put a
cap on both ends.
Tapa table - p18
1. Attach the tabletop to the table support with 3
pre-coated M6x12 bolts.
2. Now insert it into one of the four holes in the
lounger.
MAINTENANCE
Batyline
REMOVING STAINS
When dirty, after use
Use Extremis Multicleaner or common kitchen
cleaning products. Avoid using aggressive products.
These surfaces are best cleaned with a neutral cle-
aning product diluted in water.
REMOVING STUBBORN STAINS
Only if nothing else helps
Never use abrasive substances or solvents but in-
stead replace our Multi Cleaner for regular cleaning
by Serge Ferrari's specific batyline cleaner. Find
it here: en.sergeferrari.com/corporate-en/clea-
ner-500.
Powder coating
CLEANING
Regularly
Use Extremis Multicleaner, a 100% biodegradable
detergent or common kitchen cleaning products.
Avoid using aggressive products. These surfaces are
best cleaned with a neutral cleaning product diluted
in water.
REPAIRING DAMAGED POWDER-COATING
When damaged
The impact of sharp objects can damage the
coating. Scratches or dents can be touched up with
our paint pens. However this only camouflages the
scratches without removing them.
Sunbrella
SPILLED LIQUIDS
Immediately after use
It is best to treat spilt liquids immediately by placing
a sheet of absorbent kitchen paper on them. The
water-resistant coating on the Sunbrella prevents
droplets from penetrating the fabric.
23
