LABORIE PrimeSight UNITY Benutzerhandbuch Seite 6

EN
ENGLISH
SECTION 7: TECHNICAL DATA
LOAD CAPACITY
Table top payload .................................................. 13.2kg (29lbs)
Drawers payload........................................................ 2.7kg (6lbs)
Lower storage shelf payload.................................. 14.5kg (32lbs)
DIMENSIONS
Caster wheel diameter....................................................>125mm
Cart base clearance .......................................................>125mm
Shelf size ............................................. 428mm (W) x 328mm (D)
Drawer size.....................352mm (W) x 235mm (D) x 139mm (H)
Wire basket size .................................... 140mm (W) x 94mm (D)
WEIGHT
Empty .................................................................. <38.5kg (85lbs)
With payload
(cart + maximum payload)
SECTION 8: LABELS
PRODUCT LABEL
Location: Rear Center of Table Top
07-9022
Cart (with max. payload) = 68.9kg (152 lbs.)
Manufactured for Cogentix Medical, Inc.
40 Ramland Road South, Orangeburg, NY 10962 USA
MAXIMUM LOAD TABLE TOP LABEL
This label provides the maximum load allowed on the table top
and indicates the operation of the table top adjustment lever. Do
not exceed the maximum load allowed.
Location: Front right corner
MAXIMUM LOAD DRAWER LABEL
Do not exceed maximum load allowed
Location: Front right side inside the drawer
6
.................... <68.9kg (152lbs)
www.laborie.com
MADE IN USA
CGX000172 Rev. C
MAXIMUM LOAD SHELF LABEL
Do not exceed maximum load allowed
Location: Rear right side of shelf
