NOTE: The "Quick Test" function is only applicable to vehicles with all
on-board ECUs integrated into a single diagnostic socket/interface.
For vehicles with independent diagnostic interfaces for each ECU, it is
recommended to use the "Control Unit" mode for diagnostic purposes.
1.2 Control Unit
●
The "Control Unit" function lists all the possible ECUs that may be
assembled in the vehicle, allowing the user to manually select a specif-
ic ECU for testing. Upon completion of the testing process, a fault
code report can be generated.
●
System Status Indication：
"Unknown": System status is unknown whether it is installed or not.
"Installed": System is installed but fault codes have not been read.
"Not Installed": System is not installed.
"Passed": System is installed and there are no fault codes.
"Fault | (*)...": System is installed and there are (*) fault codes present.
1.3 Diagnostic Report
●
The "Diagnostic Report" function records and generates a report of
the fault code information obtained during the user's diagnostic
process. The user can view the diagnostic report by pressing the
"Report" button and can also print the report using the "Print" button.
Control Unit
[ECM] (Engine Control Module)
[ABS] (Anti-lock Brake System)
[BODY] (Body Computer)
[IP] (Instrument Cluster)
[IMMO] (Immobilizer)
F1-[Report]
F2-[Quick Erase]
6
1/7
unknown
unknown
unknown
unknown
Figure 4 -
unknown
Control Unit Mode
F3-[Pause]
